LPV-20
LEYU
| Availability: | |
|---|---|
| Quantity: | |
Introducing our robust 20W IP68 Waterproof Switching Power Supply, engineered for demanding environments. Encased in a durable, sealed plastic housing, this compact AC/DC power adapter is designed to withstand dust, moisture, and temporary immersion, making it the perfect solution for outdoor and industrial applications.
Constant voltage design
Withstand 300VAC surge input for 5 seconds
Protections: short circuit/ over load/ over voltage
Cooling by free air convection
Small and compact size
Fully encapsulated with IP67 level
Fully isolated plastic case
Class II power unit, no FG
Class 2 power unit
Pass LPS
Suitable for LED lighting and moving sign applications
100% full load burn-in test
Low cost, high reliability
2 year warranty
SPECIFICATIONS | ||||
OUTPUT | ||||
Model | LPV-20-5 | LPV-20-12 | LPV-20-15 | LPV-20-24 |
DC Voltage | 5V | 12V | 15V | 24V |
Rated Current | 3A | 1.67A | 1.33A | 0.84A |
Current Range | 0-3A | 0-1.67A | 0-1.33A | 0-0.84A |
Rated Power | 15W | 20W | 20W | 20.2W |
Ripple & Noise | 80mVp-p | 120mVp-p | 120mVp-p | 150mVp-p |
Voltage Tolerance | ±5% | |||
Setup, Rise Time | 500ms,20ms/230VAC 500ms,20ms/115VAC at full load | |||
Hold Up Time | 50ms/230VAC 16ms/115VAC | |||
INPUT | ||||
Voltage Range | 90~264VAC 47~63Hz; 127~370VDC | |||
AC Current | 0.55A/115V 0.35A/230V | |||
Efficiency | 77% | 81% | 83% | 83% |
Inrush Current | Cold start 70A/230V | |||
Leakage Current | <0.25mA/240VAC | |||
PROTECTION | ||||
Over Load | 110%~150% rated power | |||
Protection type: Shut down o/p voltage, recovers automatically after fault condition is removed | ||||
Over Voltage | 5.75-6.75V | 13.8-16V | 17.5-21V | 28-32V |
Protection type:Shut off o/p voltage, clamping by zener diode | ||||
ENVIRONMENT | ||||
Working Temp., Humidity | -30℃~+70℃; 20%~90%RH non-condensing | |||
Storage Temp., Humidity | -40℃~+80℃; 10%~95%RH | |||
Temp. Coefficient | ±0.03%/℃(0~50℃) | |||
Vibration | 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Zaxes | |||
SAFETY | ||||
Withstand Voltage | I/P-O/P: 3KVAC | |||
Isolation Resistance | I/P-O/P>100M Ohms/500VDC25℃/70%RH | |||
STANDARD | ||||
Safety Standard | Design refer to UL879, UL1310,CSA C22.2 No.207-M89, CAN/CSA C22.2 No.223-M91,TUV EN60950-1,IP67 Approved | |||
EMC Standard | Design refer to EN55022(CISPR22) Class B,EN61000-3-2 Class A, EN61000-3-3 | |||
OTHERS | ||||
Dimension | 118*35*26mm(L*W*H) | |||
Weight | 0.22Kg | |||
Packing | 60pcs/carton/14.2Kg/0.62CUFT | |||
NOTE | ||||
1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. 2.Ripple & noise are measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor. 3.Tolerance: includes set up tolerance, line regulation and load regulation. | ||||
Meet the ultimate power solution for applications where durability is non-negotiable. Our 20W IP68 Waterproof Switching Power Supply is meticulously designed to deliver unwavering performance in outdoor, industrial.
Operating Temperature : -30-70℃，suitable for both freezing and high-heat environments.
Outdoor LED Lighting: Signage, garden lights, street decorations.
Security & Surveillance Systems: Outdoor CCTV cameras, access control panels.
Industrial Automation: Sensors, controllers, alarms
Q:What is your minimum order quantity?
A:1 Piece
Q:Can I have my brand logo printed on the product?
A:Of course, we support OEM/ODM.
Q:What does wide voltage input (AC 90-264V) mean? How does it benefit me?
A:This means the power supply can automatically adapt to the electricity voltage in most regions worldwide, whether it's 110V in the United States, 230V in Europe, or areas with fluctuating voltages. You don't need to worry about damaging the power supply due to voltage mismatch, and there's no need to change adapters when traveling or exporting the device.
