A step‑by‑step sizing, selection, and installation guide focused on Leyu Power’s MDR, NDR, and LPV DIN-rail families. No third‑party datasheets, no hidden downloads — just actionable engineering steps. By the end, you will have a spec‑checked bill of materials (BOM) ready for your PLC cabinet, compliant with IEC 60204‑1 and UL 508.
Industrial automation keeps expanding. The global DIN‑rail power supply market is projected to reach ≈ $2.5 billion by 2030 (CAGR 6 %), driven by Industry 4.0 retrofits, smart‑factory builds, and edge‑IIoT deployments. These compact AC/DC bricks snap onto a standard metal rail, feeding everything from PLC CPUs to vision systems and solenoid banks.
With proper headroom, derating, and component choice (e.g., long‑life electrolytic capacitors), a DIN‑rail supply can operate 10 years or more without a fan — critical for unattended or remote cabinets.
| Rail code | Width × Height | Typical use |
|---|---|---|
| TS35 × 7.5 | 35 mm × 7.5 mm | 95 % of industrial cabinets (default) |
| TS35 × 15 | 35 mm × 15 mm | Heavy devices, large contactors, some PSUs |
| G‑type 15 | 15 mm × 5.5 mm | Miniature terminal blocks & relays |
Design rule: Allow at least 7.5 mm air gap on each side of the PSU for clip clearance and natural convection.
| Parameter | Leyu spec target | Why it matters |
|---|---|---|
| Input range | 88 – 264 VAC (universal) | Global mains compatibility, no selector switch |
| Output tolerance | ±1 % (typical) | Stable rails for PLC analog cards & sensors |
| Ripple & noise | ≤ 100 mVpp @ 20 MHz BW | Prevents analog drift, false triggering |
| Efficiency | ≥ 90 % at full load | Lower cabinet temperature, reduced OpEx |
| MTBF | ≥ 300 k hours @ 25 °C | Predictable preventive replacement intervals |
| Hold‑up time | > 20 ms @ 230 VAC | Ride‑through short voltage sags (SEMI F47‑ready) |
| Series | Power range | Key advantage |
|---|---|---|
| MDR | 15 – 60 W | Ultra‑slim (22.5 mm for 20 W); DC‑OK relay contact; ideal for dense I/O stacks |
| NDR | 75 – 480 W | Wide input, active PFC (>0.95); “‑P” models support active current‑sharing |
| LPV | 35 – 300 W | IP67 epoxy‑potted housing – dust‑tight, washdown‑ready; outdoor / food sites |
Pro tip: For cost‑sensitive general panels, choose NDR. For space‑constrained or signal‑monitoring applications, choose MDR. For wet/dusty environments, choose LPV.
The golden rule:Sum steady currents → add inrush weighting → add 20 % future buffer → apply temperature derating → round up to next nominal wattage.
| Device | Qty | Steady I (A) | Inrush × | Duty % | Peak I (A) | Weighted I (A) |
|---|---|---|---|---|---|---|
| PLC CPU | 1 | 1.2 | 1.0 | 100 | 1.2 | 1.2 |
| Servo drive | 2 | 2.0 | 1.8 | 40 | 3.6 | 2.9 |
| HMI panel | 1 | 0.6 | 1.0 | 100 | 0.6 | 0.6 |
| Totals | 5.4 | 4.7 |
Weighted I = Σ (Steady × Duty %) + Σ [ (Inrush – Steady) × Duty %/100 ], but for simplicity use peak × (duty%/100) for short‑duration loads.
Most industrial panel guidelines (IEC 60204‑1, UL 508A) recommend 20 % spare capacity for future I/O modules, sensors, or communication gateways.4.7 A × 1.20 ≈ 5.6 A
Leyu NDR series delivers 100 % load up to +50 °C ambient, then derates linearly to 50 % at +70 °C.
If your cabinet reaches +55 °C (common in summer or enclosed spaces):
I_derated = 5.6 A × [1 − 0.025 × (55 − 50)] = 5.6 × 0.875 ≈ 4.9 A
Selection: NDR‑120‑24 (24 V, 5 A, 120 W). For N+1 redundancy, parallel two NDR‑120‑24‑P (‑P = active current sharing).
| Protection | Trip point | Recovery | Standard reference |
|---|---|---|---|
| OVP | 115 – 140 % V<sub>OUT</sub> | Latch; power cycle required | IEC 61010‑1 |
| OCP | 105 – 140 % I<sub>OUT</sub> | Hiccup mode, auto‑resume | |
| SCP | Short circuit | Hiccup / constant current | |
| OTP | Internal > +100 °C | Auto‑restart after cool‑down |
Mandatory certifications for 2025 – 2026:
| Target market | Required mark |
|---|---|
| European Union | CE (LVD + EMC) + UKCA |
| USA / Canada | UL 508 (Industrial control eq.) |
| International | CB Scheme (IEC 62368‑1 / 61010‑1) |
| China | CCC |
| Global | RoHS, REACH |
EMC compliance: Industrial environments require EN 61000‑6‑2 (immunity) and EN 61000‑6‑4 (emissions). Also check EN 55032 Class B for residential/light‑industrial areas.
Mounting orientation: Vertical (airflow upward) preferred; horizontal mounting costs ≈ 15 % extra derating – always check the datasheet curve.
Clearances: ≥ 25 mm above and below the PSU. Keep wiring ducts away from ventilation slots.
DIN‑clip torque: Max 0.6 N·m – over‑torquing distorts the rail and may crack the clip.
Conformal coating: Specify for RH > 90 % or salt‑fog / chemical environments (e.g., wastewater, marine). Extends PCB life significantly.
Wire gauge: Use AWG 18 (0.82 mm²) for ≤ 5 A. Derate one size per +10 °C above 40 °C ambient.
Twist +V and –V conductors together – this shrinks the EMI loop area and reduces radiated emissions.
Surge protection: In high‑lightning‑risk areas, add a Type 2 SPD (IEC 61643‑11) upstream on the AC side.
Negative rail bonding: Bond –V to PE (protective earth) at one point only to avoid ground loops that disturb analog signals.
| Interval | Action |
|---|---|
| Startup | Verify “DC OK” LED steady; measure output voltage (adjust trim pot to ±1 % of 24 V). |
| 18 months | ESR‑test electrolytic capacitors (in‑circuit meter); replace if ESR > 2× spec. |
| 3 years | Infrared thermal scan – flag hotspots > 85 °C (loose terminals, failing caps). |
| 8–10 years | Proactively replace the PSU during scheduled downtime. Recycle per WEEE. |
Why 8‑10 years? Even with good design, electrolytic capacitor dry‑out and fan‑bearing wear (if any) limit service life. Leyu’s fanless construction removes one failure mode.
| Symptom | Likely cause | Fix |
|---|---|---|
| LED blinks at 2 Hz | OCP engaged (overload / short) | Check output wiring, measure load current. |
| Output 0 V, LED off | OTP tripped (overtemperature) | Improve airflow, clean vents, reduce ambient. |
| Output 27 V (way high) | OVP latched due to internal fault | Cycle AC mains, verify trim pot setting. |
| Erratic PLC inputs | Excessive ripple / noise (>120 mV) | Increase output capacitance, check grounding. |
Copy this list into your purchase requisition:
Rail type & length: TS35 × 7.5 (standard) / TS35 × 15 (deep) – measure cabinet.
Input voltage: Single‑phase (230 VAC) / Three‑phase (400 VAC) – clarify with site.
Output voltage & current: e.g., 24 V DC, 5 A continuous + 20 % buffer.
Max ambient temperature inside the panel (+40 °C, +55 °C, etc.) – apply derating.
Required safety marks: UL 508, CE, CCC, EAC – specify destination country.
Special features: DC‑OK relay (MDR), current‑sharing (NDR‑P), conformal coating.
Future I/O expansion (yes / no) – if yes, add another 10‑20 % capacity.
Tick every box, and a Leyu MDR, NDR, or LPV unit will slap into your rail with full code compliance.
Founded 2005 – 18+ years of switching PSU manufacturing.
ISO 9001:2015 certified – strict quality management.
Export to 50+ countries – UL, TUV, CE, CB, CCC, EAC approvals available.
2‑year warranty as standard; OEM customization (labels, cables, voltages) in 2‑4 weeks.
Real‑world MTBF > 300 k hours @ 25 °C (Telcordia SR‑332).
Leyu’s MDR, NDR, and LPV series are field‑proven in hundreds of thousands of installations – from automotive assembly lines to solar tracking controllers.
| Question | Answer |
|---|---|
| What safety standards must a DIN‑rail PSU meet for industrial panels? | Minimum: IEC 61010‑1 (electrical safety) and EN 55032 (EMC). For North America: UL 508 listing is the norm. For semiconductor tools: SEMI F47 (voltage sag ride‑through). |
| How do I properly account for temperature when sizing? | Always consult the derating curve in the datasheet. Above +50 °C ambient, reduce output current by ≈ 2 % per °C or add forced‑air cooling. Never assume full load at high temperature. |
| Can Leyu DIN‑rail PSUs share current in parallel? | Yes – models with a “‑P” suffix (e.g., NDR‑120‑24‑P) include active current‑sharing. Set output voltages within ±50 mV before paralleling, then connect the sharing bus. |
| What is the typical service life? | Leyu specifies MTBF > 300 000 h at 25 °C. Under real industrial conditions (≤ 50 °C, ≤ 80 % load), expect 8‑10 years of continuous service – then replace electrolytic capacitors or the whole unit. |
| Is field wiring required to be copper only? | IEC 60204‑1 recommends copper conductors for control circuits. If aluminium is used (rare in PSU wiring), apply antioxidant paste and torque‑check annually because of creep. |
| How do I get a custom output voltage or label? | Contact Leyu’s OEM department. Minimum order quantity may apply, but many bespoke variants (e.g., 28 V, 15 V) are possible with 4‑week lead time. |
This handbook gives you engineering‑grade, ready‑to‑use procedures – not marketing fluff. You have:
A validated 7‑step sizing method with a real example.
Derating rules that prevent field failures.
Compliance checklists for UL, CE, and industrial EMC.
A vendor‑specific cheat sheet (MDR / NDR / LPV) to speed up BOM creation.
Maintenance intervals and troubleshooting – directly usable by your panel shop.
For procurement professionals and control engineers, this is a one‑stop reference that reduces design risk and cuts hours of datasheet hunting. Bookmark it, share it with your team, and keep it open when you specify your next DIN‑rail power supply.
Leyu Power – Yueqing Leyu Electric Automation Co., Ltd. – provides the products referenced above. All technical claims are backed by publicly available datasheets and independent test reports. Always verify latest certifications for your target country before ordering.
